Customizable UEW 0.2mm * 40 Strands Twisted Enameled Copper Silk Covered Litz Wire

Informasi Dasar

Tempat asal:	CINA
Nama merek:	RVYUAN
Sertifikasi:	ISO9001/ISO14001 /UL/SGS
Nomor model:	USTC

Kuantitas min Order:	10kg
Harga:	negotiable
Kemasan rincian:	Spool dengan karton
Waktu pengiriman:	2-15 hari kerja
Syarat-syarat pembayaran:	T/ t/ paypal
Menyediakan kemampuan:	Memenuhi permintaan Anda

Harga terbaik Hubungi sekarang

Informasi Detail

Diameter:	0.2mm	Suhu:	155
Sertifikasi:	IEC/NEMA/JIS/RoHS/ISO	Konduktor:	Tembaga
Untaian:	40	Tegangan kerusakan:	Minimal 1600
Bahan penutup:	nilon	Nama Produk:	UEW 0.2mm * 40 Helai Kawat Litz Tertutup Sutra Tembaga Enamel yang Dapat Disesuaikan
Kata kunci:	UEW 0.2mm * 40 Helai Kawat Litz Tertutup Sutra Tembaga Enamel yang Dapat Disesuaikan
Menyoroti:	customizable enameled copper litz wire , 40 strands twisted litz wire , 0.2mm silk covered litz wire

Deskripsi Produk

Customizable UEW 0.2mm * 40 Strands Twisted Enameled Copper Silk Covered Litz Wire

This superior conductor features 0.2mm single-strand enameled wire coated with a durable polyurethane layer, ensuring excellent solderability. You can use it with confidence; soldering will be seamless, making it a reliable choice for a wide range of projects. The conductor is composed of 40 strands, combining exceptional flexibility and performance.

Product Specifications

Item	Technical requests	Test value 1	Test value 2
Single Diameter (mm)	0.216-0.231	0.219	0.223
Conductor diameter (mm)	0.2± 0.003	0.198	0.2
O.D. (mm)	Max.1.8	1.57	1.70
Resistance Ω/m (20℃)	Max. 0.01443	0.01357	0.01335
Breakdown Voltage V	1600	3800	3600
Pitch mm	33 ±7	√	√
No. of strands	40	√	√

Customizable UEW 0.2mm * 40 Strands Twisted Enameled Copper Silk Covered Litz Wire

customizable enameled copper litz wire

40 strands twisted litz wire

0.2mm silk covered litz wire
